Model
IGAT-180
In-Ground Automatic 180° Seat
Turn
ADA-Compliant |
| -Automatic 180° Seat Turn** |
| -Lifts up to 400 LBS. at 55-65
PSI |
| -Powered by Water Pressure |
| -Installs in Deck Socket (included)
|
| -Portable (Lift Out and Roll Away) |
| -Flip-Up Footrest Included |
| -Can Be Padlocked at Deck Level |
| -Allows Independent
Operation |
| * Note that the
pressure requirement for a faucet or hose connection is approx. 10% higher.
Click on a name below to see video of IGAT-180 in
use. |
|
Aquatic Access Model
IGAT-180/135
|
|
|
|
|
In-Ground, Automatic 135° Seat Rotation for
Pools and Spas with Built-In Benches or Seats. Designed to meet ALL ADA
guidelines.
—
Automatic 135°clockwise seat turn
—
Lifts 400 lbs. at 55-65 PSI, depending on weight of accessories
chosen
—
Portable - lifts out and rolls away with no
tools
—
Height of the lift in raised position varies up to
7'1"
Model
IGAT-180/135 allows the user's feet on the footrest to avoid built-in benches
and descends in deeper center of the pool/spa. A rubber pad under the seat
protects bench.
Standard unit
rotates clockwise, opposite turn (opposite facing seat) is available.
|
|
|
|
 |
Accessories
|
-
Flip-up left outer arm (shown in raised
position)
-
Headrest - soft, full support, with adjustable
height
-
Seat belts - seats slotted for chest and
lap locations
-
Vinyl-liner pool wall pad for IGAT models
- prevents rubbing on liner (not shown)
-
Extra recessed sockets and socket covers
- to allow use in other locations (not shown)
-
Rescue board for spinal support (must be
ordered with lift)
-
Green or blue seats available.
|
|
|
|
NEW!
The Aquatic Access IGAT-180 can be ordered equipped with a rescue board for
spinal support. This option must be ordered with the lift to ensure proper
configuration of the lift. Built of rugged, lightweight polyethylene, the
Aquatic Access Rescue Board measures 72" x 16" and weights 15 pounds. It
is rated to hold 400 lb. and is bright yellow in color.
 |
| Model
IGAT-180AD |
| In-Ground
Above-Deck |
|
|
| -Meets or exceeds current recommendations and future requirements
of the ADA. |
| -Automatic 180º Clockwise Seat Turn **
|
| -Elevated Deck Clearance to allow for automatic
pool covers or pool/spa combinations. |
| -Powered by Water Pressure -- lifts up to 350
LB. at 55 PSI while lifting or approx. 60 PSI static
faucet pressure. * |
| -Vertical Seat Travel - 42" |
| -Installs in Deck Socket (Socket Cover
included) |
| -Portable (Lift Out and Put Away) |
| -Flip-Up Footrest Included |
| -Can Be Padlocked in Seat-Up
Position |
| -Allows Independent Operation |
| * Note that the pressure
requirement for a faucet or hose connection is approx. 10% higher to achieve
our rated load.
Readbelow for more detail. |
|
